The management IP address of a device is the IP address that is used to access the device for configuration and monitoring purposes. It is usually assigned to a dedicatedmanagement interface that is separate from the data interfaces. The management interface can be accessed via SSH, Telnet, HTTP, or other protocols.

In the exhibit, the list of interfaces and their statuses shows that the management interface isme0. This interface has an admin status ofup, a protocol status ofinet, a local address of172.23.12.100/24, and a remote address ofunspecified. This means that the me0 interface is active, has an IPv4 address assigned, and is not connected to another device.

Therefore, the management IP address of the device shown in the exhibit is172.23.12.100.

References:

[Management Interfaces Overview] : [Displaying Interface Status Information]

The BGP attribute that you would use to forward all Internet traffic through the R1 device is the local preference1.

The local preference is an attribute that is used within an autonomous system (AS) and exchanged between iBGP routers1. It is used to select an exit point from the AS1. The path with the highest local preference is preferred1. By setting a higher local preference for the routes received from R1, you can make R1 the preferred exit point for all Internet traffic1.

• The exhibit shows the output of the command show ospf neighbor, which displays information about the OSPF neighbors on a router1.
• The output shows that the OSPF neighbor with the address 172.26.1.1 and the interface ge-0/0/3.0 is in the Exstart state1.
• The Exstart state is the fourth state in the OSPF neighbor formation process, after Down, Init, and 2-Way states2. In this state, the OSPF neighbors establish a master-slave relationship and exchange database description (DBD) packets, which contain summaries of their link-state databases2.
• The most common reason for OSPF neighbors to be stuck in the Exstart state is an MTU mismatch between the interfaces3. MTU stands for maximum transmission unit, which is the largest size of a packet that can be transmitted on a network segment4. If the MTU values of two OSPF neighbors are different, theymay not be able to exchange DBD packets successfully, as some packets may be dropped or fragmented due to their size exceeding the MTU limit3.
• To solve this problem, you need to ensure that the MTU values of both OSPF neighbors are the same or compatible. You can use the command show interfaces to display the MTU value of an interface5. You can also use the command ping with the do-not-fragment option to test the MTU size between two routers. You can change the MTU value of an interface by using the command set interfaces interface-name mtu mtu-value in configuration mode5.
