M2 Sample Questions Answers

For a Type B gas vent with a listed vent cap terminating through a flat roof , the minimum required termination height is 1 foot above the roof . That makes Option A correct. This is consistent with gas vent termination tables used with listed Type B vent systems and the code framework for Type B vent terminations.

The IMC requires air removed by a mechanical exhaust system to be discharged outdoors to an approved location and not be readily drawn back into the building. That makes D correct. The code does not permit general exhaust air to terminate in an attic, and it does not make filtering or recirculation the default rule for mechanically exhausted air.

Based on the specification sheet shown in the exhibit, the design features state that the optional integral clearance reduction system meets the requirements of NFPA 96 . Therefore, the correct answer is D .

The IMC states that solar thermal equipment exposed to vehicular traffic must be installed not less than 6 feet above the finished floor . It then gives an exception stating that this requirement does not apply where the equipment is protected from motor vehicle impact . Because the height requirement is removed by that exception, the best answer from the choices given is A, directly on finished floor . This is an inference from the exception language.

Under the ICC administrative provisions used with the mechanical code, one approved set is retained by the code official, and one approved set is returned to the applicant. The returned set must be kept on the site of the building or job while the authorized work is in progress. That directly matches Option A . It does not require return to the architect, filing with the county clerk, or retention for one year after completion.

The IFGC definition of fuel gas is: natural gas, manufactured gas, liquefied petroleum gas or mixtures of these gases . That definition directly matches Option B .

ICC clearance-reduction tables allow a listed clearance of 18 inches to be reduced to 9 inches where 24-gauge sheet metal is installed with a 1-inch ventilated airspace from the combustible wall. Therefore the correct answer is the option corresponding to 9 inches , which is B in your set.

Based on the equipment schedule shown in the exhibit, EF-2 is listed with a motor size of 1.5 horsepower . Therefore, the correct answer is C .

The ICC mechanical code requires condensate disposal components to be of approved corrosion-resistant material , and the drain line shall not decrease in size from the drain pan connection to the place of disposal. The code minimum size is 3/4 inch , so the 1/2-inch statement is incorrect, and the code is not limited to PVC only. Also, the slope requirement for horizontal drain piping is not less than 1/8 inch per foot , not 1/4 inch per foot. That makes Option A the only fully correct statement.

For this type of continuously ventilated exhaust shaft serving a multifamily building, the code requires the kitchen exhaust connection to penetrate the shaft and extend vertically not less than 22 inches without a fire damper. That matches Option D .

The IMC requires clothes dryer exhaust ducts to terminate outside the building and to be equipped with a backdraft damper at the terminal. The code also prohibits screens at dryer terminations because lint can accumulate and obstruct flow. That makes Option A correct and eliminates Option C . The other two choices describe controls not required by the dryer exhaust termination rule.

The IMC combustion-air provisions require openings used for combustion air to have a minimum cross-sectional dimension of 3 inches . Where ducts are used, they must be of the same cross-sectional area as the openings to which they connect. That makes 3 inches the correct answer, so Option B is correct.
