FCP_FSA_AD-5.0 Sample Questions Answers

From the Deployment and System Settings lesson, the Study Guide explicitly states:

" The status command shows information about the system, including firmware level, device serial number, disk usage, Windows VM status, states of the boot and data disks, and more. For VM appliances, it will also show the FortiSandbox license status. "

The key phrase is " For VM appliances, it will also show the FortiSandbox license status " — making the status command the correct choice for verifying license validity on a FortiSandbox VM deployment.

While vm-license -l shows installed Windows/Microsoft Office license keys, and vm-status shows guest VM image information, neither directly reports on the FortiSandbox appliance license validity. The status command is the definitive command for checking overall system and license status.

From the High Availability and Management lesson, the Study Guide states:

" You must configure the HA group name, password, and the virtual IP only on the primary node. After you configure those, you can add the secondary node to the group using the commands shown on this slide. "

The hc-slave command (shown as hc-worker for secondary) requires pointing to the Primary Node ' s HA interface IP , not the cluster virtual IP or the primary node ' s port1.

From the exhibit:

Primary Node port4 (HA interface) = 10.50.1.30

Secondary Node port4 = 10.50.1.40

Primary Node port1 = 10.25.1.30

Cluster Virtual IP = 10.25.1.50

The secondary node must connect to the Primary Node ' s dedicated HA communication port (port4 = 10.50.1.30) to join the cluster, making Option B the correct answer.

From the Scanning and Rating Components lesson, the Study Guide explicitly states:

" FortiSandbox allows you to modify the number of CPUs and memory assigned to a custom VM. This feature is supported on hardware models and private cloud VMs. "

Hardware models = Device-based (Option C)

Private cloud VMs = Private cloud (Option A)

Azure non-nested mode and FortiSandbox Cloud do not support custom VM creation as per the Study Guide.

From the FortiWeb Integration lesson, the Study Guide explicitly states:

" You can configure FortiSandbox file submission in a file security policy. Any files not detected by the FortiGuard antivirus engine will be uploaded to FortiSandbox. "

" You can configure FortiWeb to send attachments to FortiSandbox for additional scans to detect advanced persistent threats or zero-day attacks. "

From the Lab Guide (Exercise 1 - FortiWeb Integration):

" Click Web Protection > Input Validation > File Security. In the File Security Policy section, click Create New. Configure Send Files to FortiSandbox: Enabled. "

This confirms that File Security (Option A) is the correct location on FortiWeb to configure FortiSandbox file submission settings.

From the FortiClient EMS Integration lesson, the Study Guide states that FortiSandbox and FortiClient EMS integration helps break the kill chain by monitoring all downloads, removable media, mapped network drives, and email client file downloads — intercepting threats at the Delivery stage before they can execute on the endpoint.

Additionally, from the Attack Methodologies section: " When a USB is attached to a host protected with FortiClient, FortiClient can send the files on the USB drive to FortiSandbox for analysis, before allowing the user access to the files " — further confirming the Delivery stage focus.

The correct answer is B. 50 seconds . The Study Guide explicitly states: “FortiGate holds the file while waiting for a verdict from FortiSandbox… The default file inspection timeout, and maximum, is 50 seconds.” This is the clearest direct statement for the default timeout used with inline scanning mode on FortiGate.

The Lab Guide confirms the same design limit from the operational side. During the inline scanning exercise, it notes: “Because of the inline scanning time-out limit (maximum of 50 seconds), it ' s not recommended to submit files for VM inspection.” That reinforces that inline scanning is designed for quick decision phases such as active content, community cloud, antivirus, and static analysis, not long VM dynamic analysis jobs. Therefore, options A, C, and D are incorrect because they are far above the documented inline inspection limit. The default FortiGate inline scanning timeout is 50 seconds .

The exhibit summary says the file was “flagged by the PAIX engine” and describes it as “high-risk behavior.” The lab guide also states for a similar file analysis scenario: “The PAIX engine detected potentially malicious activity… The overall assessment is that there is a high likelihood of malicious activity.” In addition, the FortiGate integration lab explains that “FortiSandbox identified the fsa_dropper.exe file as high risk… because the advanced AI engine was able to detect malicious behaviour… at the static scan phase.” These extracts confirm that the advanced AI / PAIX engine identified the threat , so A is true .

Option D is not supported. The study guide distinguishes high risk from malicious and explains that high risk is a suspicious threat-level rating, not the same as a malicious verdict. It states that FortiSandbox groups results into ratings such as high risk, medium risk, low risk, clean, and malicious , and defines high-risk separately as a serious suspicious rating. Since the exhibit explicitly refers to high-risk behavior , not a malicious verdict, D is false as written . The duplicated B/C options are also not proven by the exhibit text provided.

If your original source intended D to say “The analysis resulted in a high-risk verdict” instead of malicious verdict , then the correct pair would be A and D .

From the Scanning and Rating Components lesson, the Study Guide explicitly states:

" The Pipeline Mode feature improves performance by allowing to scan multiple files, one at a time, without shutting down the VM instance after scanning each file. "

" FortiSandbox will continue scanning files without shutting down the VM instance, as long as the VM status hasn ' t changed. If the VM status changes, then the VM instance will shut down and will be restored for the next job. "

This precisely matches the requirement — using one VM instance for multiple sequential scan jobs without shutting down between submissions. The other options serve different purposes:

Adaptive Scan dynamically adjusts clone numbers

VM Scan Ratio controls the percentage of jobs scanned in a VM

Parallel VM Scan runs multiple VMs simultaneously for a single job

The best answer is B. enable Pipeline Mode . The FortiSandbox 5.0 Administrator Study Guide states: “The Pipeline Mode feature improves performance by allowing to scan multiple files, one at a time, without shutting down the VM instance after scanning each file.” It further explains that “FortiSandbox will continue scanning files without shutting down the VM instance, as long as the VM status hasn’t changed.” This directly improves the throughput of dynamic VM-based scanning , which is exactly what the question asks for.

The other options do not fit as well. Option A would reduce waiting time for users, but it lowers security because files could be accessed before a sandbox verdict is returned; the EMS lab profile intentionally enables “Wait for FortiSandbox Results before Allowing File Access” with a Low detection level to maintain strong protection. Option C also weakens security by making remediation apply only when the verdict “equals or exceeds the selected FortiSandbox Detection Verdict Level,” so raising it to Medium would ignore Low-risk detections. Option D enables prefiltering logic, which can reduce submissions, but it does not directly accelerate jobs that already require dynamic scanning. Therefore, Pipeline Mode is the only choice that both preserves a high security level and speeds dynamic scan processing.
